| Roll Size |
Φ200 x 250mm(L) |
| Foil Width |
Max. 230mm |
| Pressing Width |
Max. 200mm |
| Machine Speed |
0 ~ 2.0m/min |
| Pressing Speed |
0 ~ 1.0m/min |
| Roller Type |
Heating Roll Type |
| Heating Type |
Cartridge |
| Roller Drive |
AC Inverter Motor |
| Pressing Temp. |
Max. 150℃ (Nor. 90 ~ 100℃) |
| Thickness Accuracy |
±2㎛ (After Pressing) Depends on slurry material |
| Un/Rewinder Diameter |
Max. Φ200 (Max. 30kg) |
| Gap Control |
- Gap Block Type
- Lever Control (상부 Roll Up/Down)
|
| Machine Control |
Inverter Control, Button |
| Safety |
EMG Switch |
| Option |
- EPC Sensor
- Safety Cover
- Interlock Sensor
- Touch Display
|
| Power |
AC220V, 60Hz, 1Phase, 8kW |
| Dimension |
800(W) x 900(D) x 1,450(H) (mm) |
